All rolls are shipped individually via UPS. Please call 1-800-644-4032 for bulk pricing.
Protect N – MIL-PRF-131K C1
$183.00 – $365.00
Available Options:
Description
Protect N – MIL-PRF-131K TI C1
NSN 8135-00-282-0565 Roll
Barrier Material: Watervaporproof, Greaseproof, Flexible, Heat-Sealable, Class 1
Structure description: Nylon/PE/Foil/PE
Physical Properties
|
PROPERTY |
TYPICAL VALUES |
UNITS |
TEST METHOD |
| Caliper |
4.15 |
mil |
ASTM D2103 |
| Yield |
6,150 |
in2/lb |
Calculated |
| Puncture Resistance |
17-20 |
lbs |
MIL STD 3010 |
| Tensile Strength |
4,600 |
lbs/in |
ASTM D882 |
| Breaking Strength |
75 (MD) 70 (TD) |
lbs (Grab Mthd) |
MIL STD 3010 |
| COF (sealant to sealant) |
< 0.1-0.3 |
Kinetic |
ASTM D1894 |
| OTR |
<0.0001 |
cc/100 in2/day 24 hrs |
ASTM D3985 |
| WVTR |
<0.0001 |
g/100in2/day 24 hrs |
ASTM F1249 |
| Seal Strength |
15-20 |
lbs/in |
ASTM F88 |
| Suggested Sealing Conditions |
375°F, 40psi, 1sec |
||
08/03/07:9908- PROTECT N
Disclaimer:
The data presented refers to typical values only and should serve only as a guide and does not encompass normal variability, or constitute any warranty. We urge purchasers to conduct tests for suitability in their specific end use.
Additional information
| Weight | 55 lbs |
|---|---|
| Dimensions | 36 × 10 × 10 in |
| Size | 36" x 200 yards, 50" x 100 yards, 50" x 200 yards |
